Hitch
    915
    UVW
    5,600
    GVWR
    10,950
    Length
    26' 6"
    Height
    12' 2"
    Sleeps
    5
    MSRP
    $39,300
    DOWNLOAD SPEC SHEET

    OVERALL SIZE
    Exterior Height12' 2"
    Exterior Height (w/opt. AC)   12' 2"
    Exterior Length26' 6"
    Exterior Width8' 4"
    Exterior Width (w/ slide out)8' 4"
    Interior Height84

    WEIGHTS
    Hitch / Pin Weight915 lbs.
    UVW5,600 lbs.
    GVWR10,950 lbs.

    CAPACITY
    Fresh Water Capacity90 gal.
    Grey Water Capacity74 gal.
    Waste Water Capacity37 gal.
    Propane Tanks2
    LPG40
    Sleeping Capacity5
    Fuel CapacityN/A
    APPLIANCES
    Water HeaterTankless
    Refrigerator8 cu. ft.
    Furnace30,000 BTU
    AC15,000 BTU

    RUNNING GEAR
    Axles2
    Wheel Size15 in.
    Tire SizeST225/75R15LRE

    CONSTRUCTION
    Construction TypeTraditional
    Floor R-ValueR-11
    Wall R-ValueR-9
    Roof R-ValueR-40
    Slide Room R-ValueN/A
    Garage R-ValueR-11
    DIMENSIONS
    Standard Bed60 x 80
    Standard Bunk60 x 80
    Shower24 x 32
    Garage Length13' 6"

    EXTERIOR
    SlidesN/A
    Awnings1
    Awning Length17'
    EXTERIOR
    • Power Tongue Jack
    • Solar Power Inlet
    • Backup Camera Prep
    • 20# LP Bottles (2) with Cover
    • Friction Hinge Entry Door
    • Battery Kill Switch (Pass Thru)
    • Oversized Tank Capacites
    • Walk-on Roof
    • Easy Access Low Point Drain Valves
    • Main Floor Insulation (R-11)
    • Undermount Spare Tire
    • Magnetic Storage Door Catches
    • Extended Grab Handle
    • Power Awning
    • Backup Camera Prep
    • Power Tongue Jack
    • Dual 20#LP Tanks w/ Cover
    • All in One Utility Center
    • LP Quick Connect

    CONSTRUCTION
    • TPO Roof Membrane w/ Limited Lifetime Warranty
    • Insulated Storage Doors
    • Side Walls Insulation (R-9)
    • Slideroom Roof and End Wall Insulation (R-9)
    • Roof Insulation (R-40)
    • Tinted Windows
    • TV Prep with Backer
    • Heated & Enclosed Underbelly w/Suspended Tanks
    • Dedicated Heat Duct to Subfloor
    • Hi-Density Roof Insulation w/Thermofoil
    • Moisture Barrier Floor Enclosure
    • Elevated A-Frame Utility/Generator Rack
    • No Wheel Wells in Garage

    RUNNING GEAR

      FRAME & CHASSIS
        INTERIOR
        • Large Solid Bedroom Door (Master Suite)
        • Residential Bedspread
        • Cable/Sat Prep
        • Walk-in Shower
        • Power Vent Fan in Bath and Living Area
        • Medicine Cabinet with Mirror
        • ABS Tub Surround
        • Solid Hardwood Drawer Fronts
        • Solid Core Cabinet Stiles
        • Pre-Drilled and Screwed Cabinetry
        • Ball Bearing Full Extension Drawer Glides
        • Residential Countertops
        • Microwave
        • 3-Burner Range with Oven
        • USB Ports (2)
        • Upgraded Residential Furniture
        • More Power Outlets
        • 84" Interior Height
        • Solid Wood Drawer Fronts
        • LED Interior Lights

        KITCHEN
        • Deep Seated Stainless Steel Sink

        ELECTRICAL
        • Motion Sensor Lights in Key Areas
        • Detachable 30AMP Power Cord (22MAV Only)
        • Detachable 50AMP Power Cord (27MAV Only)
        • Battery Disconnect Switch
        • HD TV Antenna

        HVAC
        • 15K Main AC Ducted
        • 30K BTU Furnace
        • Attic Vent
        • EvenFlow Ductless Heating Throughout
        PLUMBING
        • High-Capacity Water Pump
        • Extra Large 2" Fresh Water Drain Valve
        • 90 Gal. Fresh Water Capacity
        • Black Tank Flush
        • High Rise Faucet
        • Tankless Water Heater
        • Easy Winterization

        BEDROOM
        • 60 x 80 Queen Bed
        • Gas Strut Lift Bed Storage

        BATHROOM
        • Foot Flush Toilet

        APPLIANCE
        • 12V 8 Cu. Ft. Refer

        ELECTRONICS
          Exterior Package
          • Power Awning
          • Detachable 50AMP Power Cord (27MAV Only)
          • Detachable 30AMP Power Cord (22MAV Only)
          • Backup Camera Prep
          • Battery Disconnect Switch
          • HD TV Antenna
          • Power Tongue Jack
          • Heated & Enclosed Underbelly w/Suspended Tanks
          • Dedicated Heat Duct to Subfloor
          • Hi-Density Roof Insulation w/Thermofoil
          • Moisture Barrier Floor Enclosure
          • Attic Vent
          • Dual 20#LP Tanks w/ Cover
          • EvenFlow Ductless Heating Throughout
          • Easy Winterization
          • All in One Utility Center
          • LP Quick Connect
          Luxury Interior Package
          • 12V 8 Cu. Ft. Refer
          • Microwave
          • 3 Burner Range
          • 15K Main AC Ducted
          • 84" Interior Height
          • 60 x 80 Queen Bed
          • 90 Gal. Fresh Water Capacity
          • Undermount Spare Tire
          • Black Tank Flush
          • Magnetic Storage Door Catches
          • Foot Flush Toilet
          • Extended Grab Handle
          • Gas Strut Lift Bed Storage
          • Tinted Windows
          • High Rise Faucet
          • Solid Wood Drawer Fronts
          • Tankless Water Heater
          • Deep Seated Stainless Steel Sink
          • TV Prep with Backer
          • LED Interior Lights
          • Motion Sensor Lights in Key Areas
          • 30K BTU Furnace
          • Radial Tires
          • Two Euro Chairs (22MAV)
          Garage / Cargo Package
          • 24" DoveTail Loading Ramp
          • 2,500lbs Tie Downs Anchored into Chassis
          • Patio System
          • Loading Lights
          • No Wheel Wells in Garage
          • E-Z Lift Bunk Bed
          • Garage Pull Down Screen
          • Garage Camera Prep
