Hitch
    2,347
    UVW
    12,198
    GVWR
    16,400
    Length
    36' 5"
    Height
    13' 6"
    Sleeps
    7
    MSRP
    $94,980

    OVERALL SIZE
    Exterior Height13' 6"
    Exterior Height (w/opt. AC)   13' 6"
    Exterior Length36' 5"
    Exterior Width8' 4"
    Exterior Width (w/ slide out)10' 9"
    Interior HeightN/A

    WEIGHTS
    Hitch / Pin Weight2,347 lbs.
    UVW12,198 lbs.
    GVWR16,400 lbs.

    CAPACITY
    Fresh Water Capacity160 gal.
    Gray Water Capacity78 gal.
    Waste Water Capacity39 gal.
    Propane Tanks2
    LPG60
    Sleeping Capacity7
    Fuel Capacity60
    APPLIANCES
    Water HeaterTankless
    Refrigerator12 cu. ft.
    Furnace35,000 BTU
    AC15,000 BTU

    RUNNING GEAR
    Axles2
    Wheel Size17.50 in.
    Tire SizeST215/75R17.5R LRH

    CONSTRUCTION
    Construction TypeAluminum Cage
    Floor R-ValueR-40
    Wall R-ValueR-11
    Roof R-ValueR-40
    Slide Room R-ValueR-7
    Garage R-ValueR-30
    DIMENSIONS
    Standard Bed60 X 80 Queen Bed
    Standard Bunk60x80
    Shower48 X 30
    Garage Length15' 3"

    EXTERIOR
    Slides2
    Awnings2
    Awning Length
    • 15'
    • 15'
    EXTERIOR
    • Black Tank Flush
    • Full Sized Spare Tire & Carrier
    • 80% Tint Radius Safety Glass Windows
    • 30lb LP Bottles (2)
    • Radius Entry Door
    • High-Capacity Water Pump
    • Extra Large 1 1/2" Fresh Water Drain Valve
    • Battery Disconnect Switch
    • Folding Roof Ladder
    • Gel Coated Fiberglass Exterior
    • Easy Access Low Point Drain Valves
    • Insulated Storage Doors
    • Large Panoramic Windows
    • Magnetic Storage and Entry Door Latches
    • Awning w/LED Accent Lighting
    • Under Unit Accent Lighting

    CONSTRUCTION
    • Oversized Tank Capacities
    • One-Piece TPO Roof Membrane w/ Limited Lifetime Warranty
    • Laminated Aluminum Framed Rear Ramp Door (R-7)
    • Laminated Aluminum Framed Side Walls (R-11)
    • Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-7)
    • 1" Marine Grade OSB Floor (R-30*)
    • 5" Radius Wood Framed Roof (R-40*)

    RUNNING GEAR
    • Upgraded Axle Hangers
    • Heavy Duty H-Rated Tires
    • Heavy Duty 7,000lb. Axles w/ ABS Drum Brakes (355G, 415G)
    • Heavy Duty 8,000lb. Axles w/ ABS Drum Brakes (320G, 325G, 350G)
    • 17.5" H-Rated Aluminum Wheels
    • MORryde CRE3000 Suspension System
    • Tow Assist ABS & Sway Mitigation System

    FRAME & CHASSIS
    • Electric Auto Leveling System
    • 101" Wide-Body Super Chassis
