This travel trailer floorplan features a rear bathroom and bunk beds with front Queen Murphy Bed.

    Hitch
    533
    UVW
    4,987
    GVWR
    6,395
    Length
    24' 11"
    Height
    10' 5"
    Sleeps
    6
    MSRP
    $40,969
    DOWNLOAD SPEC SHEET
    OVERALL SIZE
    Exterior Height10' 5"
    Exterior Height (w/opt. AC)   10' 10"
    Exterior Length24' 11"
    Exterior Width8'
    Exterior Width (w/ slide out)8'
    Interior Height78

    WEIGHTS
    Hitch / Pin Weight533 lbs.
    UVW4,987 lbs.
    GVWR6,395 lbs.

    CAPACITY
    Fresh Water Capacity37 gal.
    Gray Water Capacity45 gal.
    Waste Water Capacity37 gal.
    Propane Tanks2
    LPG40
    Sleeping Capacity6
    Fuel CapacityN/A
    APPLIANCES
    Water HeaterTankless
    Refrigerator10 cu. ft.
    Furnace25,000 BTU
    AC15,000 BTU

    RUNNING GEAR
    Axles2
    Wheel Size14 in.
    Tire SizeST205/75R14LRD

    CONSTRUCTION
    Construction TypeAluminum Cage
    Floor R-ValueR-30
    Wall R-ValueR-7
    Roof R-ValueR-40
    Slide Room R-ValueR-7
    Garage R-ValueN/A
    DIMENSIONS
    Standard Bed60x76
    Standard Bunk47 X 76
    Shower27 X 36
    Garage LengthN/A

    EXTERIOR
    SlidesN/A
    Awnings1
    Awning Length15'
    EXTERIOR
    • 80% Tint Radius Safety Glass Windows
    • 20# LP Bottles (2) w/ Level Gauges
    • 28" Radius Entry Door
    • Extra Large 2” Fresh Water Drain Valve
    • Adjustable Power Awning w/ LED Lights
    • Power Tongue Jack
    • Spare Tire & Carrier
    • Aluminum Entry Steps
    • 6' Coiled Break Away Cable
    • Front Rock Guard
    • Tuff-Ply Pass Thru Flooring
    • Sewer Hose Carrier

    CONSTRUCTION
    • Gel Coated Fiberglass Exterior
    • One-Piece Roof Membrane with Limited Lifetime Warranty
    • Easy Access Low Point Drain Valves
    • Friction Hinge Entry Door
    • Magnetic Storage Door Catches
    • Laminated Aluminum Framed Rear Wall (R-7)
    • Laminated Aluminum Framed Side Walls (R-7)
    • Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-7)
    • Laminated Aluminum Framed Main Floor (R-30)
    • 5" Radius Wood Framed Roof (R-40)
    • Heated & Enclosed Underbelly w/ Suspended Tanks
    • Double Insulated Roof & Front Wall
    • Heated & Enclosed Dump Valves
    • High Density Roof Insulation w/ Attic Vent
    • Moisture Barrier Floor Enclosure

    RUNNING GEAR
    • Tire Linc TPMS Prep
    • Aluminum Rims
    • Anti-Lock Braking System

    FRAME & CHASSIS
    • 2'' Accessory Hitch Receiver
    INTERIOR
    • Solid Drawer Fronts
    • Glass Cabinet Door Inserts (Select Overhead Cabinets)
    • Solid Core Cabinet Stiles
    • Pre-Drilled and Screwed Face Frames
    • Ball Bearing Full Extension Drawer Glides
    • Large Panoramic Window
    • Telescoping Dinette Table
    • LED Interior Lighting
    • Wireless Pop-Up Charger w/ 2 USB Outlets

    KITCHEN
    • Sink Cover
    • Residential Countertops
    • Deep Seated Stainless Steel Sink
    • Residential Pulldown Sprayer Faucet

    ELECTRICAL
    • Battery Kill Switch (Pass Thru)
    • Monitor Panel w/ One Touch Compass Connect
    • 200W Roof Mounted Solar Panel
    • Roof Mounted Quick Connect Plugs
    • 30 AMP Charge Controller
    • 30 Amp Service
    • Detachable Power Cord
    • Motion Sensor LED Entry Lighting

    HVAC
    • High Capacity Furnace
    • Designated Heat to Subfloor
    • Residential (Ductless) Heating System Throughout
    • Ducted Main A/C
    PLUMBING
    • High-Capacity Water Pump
    • Oversized Tank Capacities

    BEDROOM
    • Queen Murphy Bed w/ Storage Drawers (17MKE, 22BHE)
    • Residential Bedspread
    • Master Suite with Queen Bed (22MLE, 22RBE, 23LDE, 24BSE, 25DBE)
    • Built-in Wardrobe Cubby Storage w/USB-C Charging Station and 110V Outlet

    BATHROOM
    • Residential Walk-In Shower
    • Skylight Over Shower
    • Power Vent Fan
    • Medicine Cabinet with Mirror

    APPLIANCE
    • Microwave
    • 3-Burner Range with Oven
    • 12V 10 CU FT Refrigerator

    ELECTRONICS
      Exterior Package
      • Satellite TV Prep (All TV Locations)
      • MORryde Strut Assist Entry Step
      • Aluminum Quad Steps - Garage Entry
      • 7,000 lb. Axles w/ ABS Drum Brakes
      • 17” Aluminum Wheels (120PSI Rated)
      • Cooper Tires® 17.5" All-Steel H-Rated Tires
      • Slam-Latch Baggage Doors
      • Frameless Tinted Windows
      • Exterior Security Lights
      • Power Patio Awning w/LED Lighting
      • Folding Roof Ladder
      • White Gel Coat Fiberglass Front Cap
      • 12V Battery Disconnect
      • All-In-One Exterior Utility Center
      • 50 Amp Service
      • Converter
      • Enclosed Fuel Station w/ Dual Fuel Tank
      • Full Paint Gel Coat Fiberglass Front Cap (397TH)
      Luxury Interior Package
      • 49" Class LED TV in Living Area
      • Stereo Entertainment System w/Bluetooth and App Based Controls in Living Area
      • Washer/Dryer Prep
      • On Demand Water Heater
      • Roller Shade Window Coverings (Main Living Area and Bedroom)
      • Recessed LED Puck Lighting
      • Solid Surface Countertops w/ Sink Covers
      • Stainless Steel Undermount Kitchen Sink
      • Chef Inspired Range & Oven w/ Cover
      • Kitchen Pantry w/ LED Light Strip
      • Garage Control Panel
      Garage Package
      • 32" Class LED TV in Garage (397TH)
      • Protective Diamond Plate on Garage Sidewalls
      • 2,500 lb. Rated Flush-Mount Tie-Downs
      • Ram-Air Garage Vents Both Sides
      • Tuff-Ply Gas and Oil Resistant Garage Flooring
      • FastRamp™ Rear Ramp Door
      • Triple Insulated Garage Floor
      Weather-Tek Package
      • R-Value Equivalent (R-40 Roof / R-45 Floor / R-11 Sidewalls / R-40 Garage Floor / R-24 Slideroom Floor)
      • Fully Enclosed and Heated, Underbelly and Storage Area
      • Enclosed and Heated Low Point Drains
      • Engineered Underbelly Airflow Heat Paths
      • Stealth AC System w/ Insulated A/C Ducts
      • Attic Vent
      • Plumbing Line Insulation Barrier
